Composite body with alum. clutch housing and rear plate.
3 steps forward and reverse.
360° swivel air inlet
Lubricator fitting for impact clutch.
Vane with spring mounted for start smooth.
Impact Type: Twin Hammer
Anvil Size: 1/2 inch
Free Speed: 10,000 rpm
Working Torque: 350 ft-lb @5 Sec. / 472 Nm @5 Sec.
Max. Torque: 450 ft-lb @15 Sec. / 610 Nm @15 Sec.
Product Weight: 1.25 kg / 2.7 lb
Product Length: 125 mm / 4.92 inch
Air Consumption: 115 l/min / 4.0 cfm
Air Inlet Pressure: 6.3 kg/cm2 / 90 psi
Air Inlet Size: 1/4 inch Air Hose I.D.: 3/8 inch
Exhaust Type: Handle Exhaust
Sound Pressure: 90.5 dB(A)
Vibration Level: 3.7 m/s2
