Composite body with alum. clutch housing and rear plate.
3 steps forward and full reverse.
360° swivel air inlet.
Lubricator fitting for impact clutch.
Vane with spring mounted for start smooth.
Impact Type: Twin Hammer
Anvil Size: 1/2 inch
Free Speed: 8,500 rpm
Working Torque: 650 ft-lb @5 Sec. / 881 Nm @5 Sec.
Max. Torque: 820 ft-lb @15 Sec. / 1,111 Nm @15 Sec.
Nut-Busting Torque: 1,050 ft-lb / 1,417 Nm
Product Weight: 2.1 kg / 4.6 lb
Product Length: 190 mm / 7.48 inch
Air Consumption: 158 l/min / 5.5 cfm
Air Inlet Pressure: 6.3 kg/cm2 / 90 psi
Air Inlet Size: 1/4 inch
Air Hose I.D.: 3/8 inch
Exhaust Type: Handle Exhaust
Sound Pressure: 91.5 dB(A)
Vibration Level: 8.1 m/s2
