Composite body with Magnesium clutch housing and rear plate.
3 steps forward and full reverse.
360° swivel air inlet.
Lubricator fitting for impact clutch.
Vane with spring mounted for start smooth.
Material: anvil-SNCM616 , Cylinder-FCD45.
Impact Type: Twin Hammer
Anvil Size: 1/2 inch
Free Speed: 8,500 rpm
Working Torque: 800 ft-lb @5 Sec. / 1,080 Nm @5 Sec.
Max. Torque: 950 ft-lb @15 Sec. / 1,283 Nm @15 Sec.
Nut-Busting Torque: 1,622 ft-lb / 2,200 Nm
Product Weight: 1.65 kg / 3.6 lb
Product Length: 179 mm / 6.89 inch
Air Consumption: 158 l/min / 5.5 cfm
Air Inlet Pressure: 6.3 kg/cm2 / 90 psi
Air Inlet Size: 1/4 inch
Air Hose I.D.: 3/8 inch
Exhaust Type: Handle Exhaust
Sound Pressure 91.5 dB(A)
Vibration Level 8.1 m/s2
