Composite body with Magnesium clutch housing and rear plate.
3 steps forward and full reverse.
360° swivel air inlet.
Lubricator fitting for impact clutch.
Vane with spring mounted for start smooth.
Material: anvil-SNCM616 , Cylinder-FCD45.
Impact Type: Twin Hammer
Anvil Size: 1 inch
Free Speed: 6,000 rpm
Working Torque: 1,250 ft-lb @5 Sec. / 1,687 Nm @5 Sec.
Max. Torque: 1,550 ft-lb @15 Sec. / 2,092 Nm @15 Sec.
Nut-Busting Torque: 3,023 ft-lb / 4,100 Nm
Product Weight: 3.15 kg / 6.4 lb
Product Length: 219 mm / 8.22 inch
Air Consumption: 198 l/min / 7.0 cfm
Air Inlet Pressure: 6.3 kg/cm2 / 90 psi
Air Inlet Size: 3/8 inch
Air Hose I.D.: 3/8 inch
Exhaust Type: Handle Exhaust
Sound Pressure: 96.5 dB(A)
Vibration Level: 8.6 m/s2
